Main technical parameters
1-1 measurements elements and scope SiO2, Al2O3, Fe2O3, TiO2, CaO, MgO and K2O, Na2O, Li2O, ZrO2, CoO, P2O5, B2O3, SnO, PbO, ZnO, BaO, NiO, MnO, Cr2O3
1-2 on the following main elements for rapid analysis of chemical raw materials Chromium salt products, V2O5 products, MnO products, NiO products, titanium, phosphate, cobalt oxide, zinc oxide boric acid, borax, Tansuanbei, water glass, Fuzhisuan sodium
1-3 low content of the high-precision analysis group Will Fe2O3, TiO2, CaO, MgO and K2O, Na2O, P2O5, MnO, Cr2O3 and other elements detection limits extended to 0.02%, the analysis accuracy better than 0.02%.
2, precision analysis Precision analysis of the elements related to or better than national standards set forth in analytical methods allow errors.
3, analysis speed
2-3 hours to begin the completion of SiO2, CaO Al2O3, Fe2O3, TiO2, MgO and K2O, Na2O whole analysis, the analysis of other elements 4-6 hours to complete
4, into the kind of access : 3
5, even detected a few samples : 10
Sets of equipment,
1, GKF-based mainframe, one
2, data processing systems, one sets
3, flame photometer, one sets
4, Silver crucible crucible, and widespread sets
5, ultrasonic cleaning machine, one
Apparatus working conditions,
1, electricity, 220V 50Hz
2, whole sets of power, 1Kw
3, whole sets of weight, 100kg
4, the installation size, 3500 x 850mm workstations
